| System |
|
Main Processor
|
Dual-core embedded processor |
|
Operating System
|
Embedded LINUX |
| Display |
|
Interface
|
1 HDMI, 1 VGA
|
|
Resolution
|
1920×1080, 1280×1024, 1280×720, 1024×768 |
|
Multi-screen Display
|
1/4/8/9 |
|
OSD
|
Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
| Video Detection & Alarm |
|
Trigger Events
|
Recording, PTZ, Tour, Alarm Out, Video Push, Email, FTP,Snapshot, Buzzer & Screen tips |
|
Video Detection
|
Motion Detection, MD Zones: 396(22×18), Video Loss and Tampering |
|
Alarm Input
|
4 Channel, Low Level Effective, Green Terminal Interface |
|
Relay Output
|
2 Channel, NO/NC Programmable, Green Terminal Interface |
| Playback & Backup |
|
Playback
|
1/4 |
|
Search Mode
|
Time /Date, MD and Exact Search(accurate to second) |
|
Playback Function
|
Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom |
|
Backup Mode
|
USB Device/Network |
| Storage |
|
Internal HDD
|
2 SATA III Port, Up to 6 TB capacity for each HDD |
|
HDD Mode
|
Single |
|
eSATA
|
N/A |
| Auxiliary Interface |
|
USB
|
2 ports (1 Rear USB2.0, 1 Front USB2.0)
|
|
RS232
|
N/A
|
|
RS485
|
N/A
|
| Third-party Support |
|
Third-party Support
|
Snappy, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, and more |
| Audio and Video |
|
IP Camera Input
|
8 Channel |
|
Two-way Talk
|
1 channel Input, 1 channel Output, RCA |
