Playback & Backup |
Sync Playback
|
1/4(NVR-14R-4P), 1/4/8(NVR-18R-4P), 1/4/8/16(NVR-116R-4P) |
Search Mode
|
Time/Date, Alarm, MD & Exact search (accurate to second), Smart search |
Playback Function
|
Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom |
Backup Mode
|
USB Device/Network/Internal SATA burner |
Network |
Ethernet
|
1RJ-45 port (10/100Mbps) |
PoE
|
4 ports (IEEE802.3at/af) |
Network Function
|
HTTP, TCP/IP, IPv4/IPv6, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE, DDNS, FTP, Alarm Server, IP Search(Support Snappy IP camera, DVR, NVS and etc.) |
Max. User Access
|
128 users |
Smart Phone
|
iPhone, iPad, Android |
Storage |
Internal HDD
|
1 SATA port, up to 4TB |
Auxiliary Interface |
USB
|
2 ports (2 Rear), USB2.0
|
General |
Power Supply
|
Single, DC48V/1.5A |
Power Consumption
|
NVR: 10W(without HDD) PoE: Max 25.5W for single port
|
Working Environment
|
-10°C~+55°C / 10%~90%RH / 86~106kpa |
Dimension(W×D×H)
|
Smart 1U, 205mm×205mm×45mm |
Weight
|
0.5KG(without HDD) |
