HDD using mode
|
Single HDD、RAID0、1、5、6、10、50、60、JBOD、Hot-Spare（Hot Standby） |
|
HDD management
|
Non-working HDD sleep, in favor of heat dissipation and power consumption reduction, prolong life-span of HDD |
|
HDD processing
|
Support HDD bad tracks mapping，prolong life-span of HDD |
|
HDD status inspection
|
Support HDD preview before use、periodic inspection during use |
|
One-click RAID
|
RAID Support one-click set RAID immediately
|
|
RAID set-and-play
|
RAID can be used directly after settled
|
|
RAID reset
|
Support adjust RAID reset speed dynamically，ensure system load balance
|
|
RAID write synchronous
|
Support RAID write synchronous, ensure to data safety
|
|
Video playback
|
Support WEB-client video playback；support search by second； adjustable playback speed |
|
Port property
|
Support Ethernet-port binding or mode such as load balance, fault-tolerant
|
|
Power supply
|
100V~240V，47~63Hz，support hot-swap |
|
Fan
|
DC 12V,1.5A, flabellum diameter：80mm，support hot-swap |
|
Power Consumption
|
1000W（include HDD） |
|
Working temperature
|
0℃~40℃ |
|
Working Humidity
|
10%~80%（non-condensation） |
|
Storage Temperature
|
-20℃～70℃ |
|
Storage Humidity
|
5%~90%（non-condensation |
|
Working Elevation
|
-60m~5000m |
|
Chassis
|
Hot-dip galvanized steel sheet(1.2mm thickened) High-precise aluminum alloy slide Self-patent drawer-type HDD rack |
|
Dimension(W×D×H)
|
444.4mm*352.8mm*494m（without lug）
444.4mm*352.8mm*532mm（with lug） |
|
Weight
|
49.92Kg（exclude external packing, exclude HDD) |
|
Mounting
|
19 feet standard rack-mounted |
