1KVA
Features Technical Specifications Downloads High Resolution Images
1KVA
Model : BM0KB

Features

  • DSP Technology
  • Environment Friendly
  • Active input power factor correction(PFC)
  • Wide range of input voltage and frequency
  • Zero power switch delay
  • Adaptive Load Management
  • Sufficient Expansion Slots
  • The load PFC is 0.8
  • Support the generator

Technical Specifications

UPS System Model BM0KB
Capacity 1KVA/800W
Input
Voltage 115 - 300Vac
Frequency 40-60Hz Adjustable
Power factor 0.99
Output
Voltage 220/230Vac( 1± 2% )
Frequency Synchronize with utility power(utility mode); 50/60Hz ± 0.2Hz(battery mode)
On-load factor 0.8
Overload rating 125% overload,1min
Battery
Type Valve-control lead acid maintenance-free battery
Back up time more than 11min(half load)
Rated voltage 36V
General
Transfer time 0
Operating environment Humidity: 20%-90%, Temperature:40°C
Size (WxDxH)mm 350X144X229
Net Weight(kg) 11.5

Downloads

1

Catalog : 1KVA

Click below link to download the catalog for the 1KVA- Model : BM0KB

Download Catalog
