| System |
|
Main Processor
|
Dual-core embedded processor |
|
Operating System
|
Embedded LINUX |
| Display |
|
Interface
|
1 HDMI, 1 VGA |
|
Resolution
|
1920 × 1080, 1280 × 1024, 1280 × 720, 1024 × 768 |
|
Multi-screen Display
|
8CH: 1/4/8/9
16/32CH: 1/4/8/9/16
|
|
OSD
|
Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
| Video Detection and Alarm |
|
Trigger Events
|
Recording, PTZ, Tour, Alarm Out, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips |
|
Video Detection
|
Motion Detection, MD Zones: 396 (22 × 18),Video Loss and Camera Blank |
|
Alarm input
|
4 Channel, Low Level Effective,Green Terminal Interface |
|
Relay Output
|
2 Channel, NO/NC Programmable,Green Terminal Interface |
| Playback and Backup |
|
Playback
|
8CH: 1/4/8
16/32CH: 1/4/8/16
|
|
Search Mode
|
Time /Date, Alarm, MD and Exact Search(accurate to second), Smart search |
|
Playback Function
|
Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom |
|
Backup Mode
|
USB Device/Network |
| Storage |
|
Internal HDD
|
2 SATA III Ports, Up to 6TB capacity for each HDD |
|
HDD Mode
|
Single |
|
eSATA
|
N/A |
| Auxiliary Interface |
|
USB
|
3 USB Ports (2 USB 2.0 , 1 USB 3.0 ) |
|
RS232
|
N/A |
|
RS485
|
N/A |
| Third-party Support |
|
Third-party Support
|
Snappy, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, and more |
| Audio and Video |
|
IP Camera Input
|
8/16/32 Channel |
|
Two-way Talk
|
1 Channel Input, 1 Channel Output, RCA |
