| Camera |
|
Image Sensor
|
1/1.9” 2Megapixel progressive scan CMOS |
|
Effective Pixels
|
1920(H)x1080(V) |
|
RAM/ROM
|
1024MB/128MB |
|
Scanning System
|
Progressive
|
|
Minimum Illumination
|
0.001Lux/F1.2 (Color), 0.0001Lux/F1.2 (B/W) |
|
S/N Ratio
|
More than 50dB
|
|
IR Distance
|
N/A
|
|
IR On/Off Control
|
N/A
|
|
IR LEDs
|
N/A
|
| Lens |
|
Lens Type
|
N/A |
|
Mount Type
|
C/CS |
|
Focal Length
|
N/A |
|
Max. Aperture
|
N/A |
|
Angle of View
|
N/A |
|
Optical Zoom
|
N/A |
|
Focus Control
|
N/A |
|
Close Focus Distance
|
N/A |
| Pan/Tilt/Rotation |
|
Pan/Tilt/Rotation Range
|
N/A |
| Intelligence |
|
IVS (optional)
|
Tripwire, Intrusion, Object Abandoned/Missing |
|
Advanced Intelligent Functions
|
Face Detection, People Counting, Heat Map |
| Video |
|
Compression
|
H.265/H.264 |
|
Streaming Capability
|
3 Streams |
|
Resolution
|
1080P(1920×1080)/ 1.3M(1280x960)/ 720P(1280x720)/ D1(704×576/704x480)/ VGA(640x480)/ CIF(352×288/342x240) |
|
Frame Rate
|
|
Main Stream
|
1080P(1~50/60fps)
|
|
Sub Stream
|
D1 (1 ~ 50/60fps)
|
|
Third Stream
|
1080P(1~50/60fps)
|
|
Bit Rate Control
|
CBR/VBR |
|
Bit Rate
|
H.264: 24~ 10240Kbps,H.265: 14~ 6144Kbps |
|
Day/Night
|
Auto(ICR) / Color / B/W |
|
BLC Mode
|
BLC / HLC / DWDR/ SSA |
|
White Balance
|
Auto/Natural/Street Lamp/Outdoor/Manual |
|
Gain Control
|
Auto/Manual |
|
Noise Reduction
|
3D DNR |
|
Motion Detetion
|
Off / On (4 Zone, Rectangle) |
|
Region of Interest
|
Off / On (4 Zone) |
|
Electronic Image Stabilization (EIS)
|
Support |
|
Smart IR
|
N/A |
|
Defog
|
Support |
|
Digital Zoom
|
16x |
|
Flip
|
0°/90°/180°/270° |
|
Mirror
|
Off / On |
|
Privacy Masking
|
Off / On (4 Area, Rectangle) |
