Playback & Backup |
Sync Playback
|
1/4/8(NVR-48R-8P), 1/4/8/16(NVR-416R-8P), 1/4/8/16(NVR-432R-8P) |
Search Mode
|
Time/Date, Alarm, MD & Exact search (accurate to second), Smart search |
Playback Function
|
Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom |
Backup Mode
|
USB Device/Network/Internal SATA burner/eSATA Device |
Network |
Ethernet
|
1 RJ-45 port (10/100/1000Mbps) |
PoE
|
8 ports (IEEE802.3at/af) |
Network Function
|
HTTP, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE, DDNS, FTP, Alarm Server, IP Search(Support Snappy IP camera, DVR, NVS and etc.) |
Max. User Access
|
128 users |
Smart Phone
|
iPhone, iPad, Android |
Storage |
Internal HDD
|
4 SATA ports, up to 16TB |
External HDD
|
1 eSATA port |
Auxiliary Interface |
USB
|
2 ports (1 Rear USB3.0,1 Front USB2.0)
|
RS232
|
1 port, For PC communication & Keyboard
|
RS485
|
1 port, For PTZ control
|
General |
Power Supply
|
AC 100V~240V,50/60HZ |
Power Consumption
|
NVR: 40W(without HDDP) PoE: Max 25.5W for single port
|
Working Environment
|
-10°C~+55°C/10%~90%RH/86~106kpa |
Dimension(W×D×H)
|
1.5U, 440mm×413mm×75mm |
Weight
|
6KG(without HDD) |
