| System |
|
Main Processor
|
Dual-core embedded processor |
|
Operating System
|
Embedded LINUX |
| Audio and Video |
|
IP Camera Input
|
4 Channel |
|
Two-way Talk
|
1 Channel Input, 1 Channel Output, RCA |
| Display |
|
Interface
|
1 HDMI, 1 VGA |
|
Resolution
|
1920×1080, 1280×1024, 1280×720, 1024×768 |
|
Multi-screen Display
|
1/4
|
|
OSD
|
Camera title, Time, Camera lock, Motion detection, Recording |
| Recording |
|
Compression
|
H.264/H.264 |
|
Resolution
|
6Mp/5Mp/4Mp/3Mp/1080P/ 720P/ D1 & etc. |
|
Record Rate
|
80Mbps |
|
Bit Rate
|
16kbps ~ 20Mbps for per channel |
|
Record Mode
|
Manual, Schedule (Regular, Continuous), MD, Stop |
|
Record Interval
|
1 ~ 120 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec |
| Video Detection and Alarm |
|
Trigger Events
|
Recording, PTZ, Tour, Video Push, Snapshot, and Screen Tips |
|
Video Detection
|
Motion Detection, MD Zones: 396 (22 × 18), and Tampering |
|
Alarm input
|
N/A |
|
Relay Output
|
N/A |
| Playback and Backup |
|
Sync Playback
|
4CH: 1/4
|
|
Search Mode
|
Time /Date, MD and Exact Search (accurate to second) |
|
Playback Function
|
Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom |
|
Backup Mode
|
USB Device/Network |
| Third-party Support |
|
Third-party Support
|
Snappy, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, and more |
