| System |
|
Main Processor
|
Quad-core embedded processor |
|
Operating System
|
Embedded LINUX |
| Display |
|
Interface
|
2 HDMI, 2 VGA |
|
Resolution
|
HDMI1: 3840 × 2160 , 1920 × 1080 , 1280 × 1024, 1280 × 720 , 1024 × 768 |
|
Multi-screen Display
|
1st Screen: 16CH: 1/4/8/9/16 32CH:1/4/8/9/16/25/36 64CH: 1/4/8/9/16/25/36/64 2nd Screen: 1/4/8/9/16 |
|
OSD
|
Camera title, Time, Camera lock, Motion detection, Recording |
| Video Detection & Alarm |
|
Trigger Events
|
Recording, PTZ, Tour, Alarm Out, Video Push, Email,Snapshot, Buzzer & Screen tips |
|
Video Detection
|
Motion Detection, MD Zones: 396(22×18), Video Loss & Tampering |
|
Alarm Input
|
16 Channel |
|
Relay Output
|
6Channel |
|
Tracking Trigger Event
|
N/A |
| Playback & Backup |
|
Sync Playback
|
1/4/9/16 |
|
Search Mode
|
Time/Date, Alarm, MD & Exact search (accurate to second) |
|
Playback Function
|
Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Backup selection, Digital zoom |
|
Backup Mode
|
USB Device/Network/eSATA Device |
| Storage |
|
Internal HDD
|
8 SATA III ports, up to 10TB capacity for each HDD |
|
HDD Mode
|
Single |
|
eSATA
|
1 eSATA port |
|
SAS
|
N/A
|
| Auxiliary Interface |
|
Front Cover
|
N/A
|
|
USB
|
4 USB ports (2 Rear USB 3.0,2Front USB 2.0)
|
|
RS232
|
1 port, For PC communication & Keyboard
|
|
RS485
|
1 port, For PTZ control
|
| Third-party Support |
|
Third-party Support
|
Arecont Vision, Airlive, AXIS, Canon, Dynacolor,JVC, LG, Panasonic, Pelco, PSIA, Samsung, Sanyo,Sony, Watchnet and more
|
| Audio & Video |
|
IP Camera Input
|
16/32/64 Channel |
|
Two-way Talk
|
1 channel Input, 2 channel Output, RCA |
