| System |
|
Main Processor
|
Intel Dual-core Processor |
|
Operating System
|
Embedded LINUX |
| Video & Audio |
|
IP Camera Input
|
32 Channel |
|
Two-way Talk
|
1 channel Input, 1 channel Output, RCA |
| Display |
|
Interface
|
2 HDMI (up to 3840 x 2160 , Different Source), 1 VGA
|
|
Resolution
|
3840 × 2160 , 1920 × 1080 , 1280 × 1024,1280 × 720 , 1024 × 768 |
|
Multi-screen Display
|
1st Screen: 1/4/8/9/16/25/36
2nd Screen: 1/4/8/9/16
|
|
OSD
|
Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
| Recording |
|
Compression
|
H.265/H.264/MJPEG |
|
Resolution
|
12MP, 8MP, 6MP, 5MP, 4MP, 3MP, 1080P, 1.3MP, 720P etc |
|
Record Rate
|
384Mbps |
|
Bit Rate
|
16Kbps ~ 20Mbps Per Channel |
|
Record Mode
|
Manual, Schedule (Regular, MD (Motion Detection), Alarm, IVS), Holiday, Stop |
|
Record Interval
|
1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec |
| Video Detection & Alarm |
|
Trigger Events
|
Recording, PTZ, Tour, Alarm Out, Video Push, Email, FTP,Snapshot, Buzzer & Screen tips |
|
Video Detection
|
Motion Detection, MD Zones: 396(22×18), Video Loss and Tampering |
|
Alarm Input
|
16 Channel, Low Level Effective, Green Terminal Interface |
|
Relay Output
|
8 Channel, NO/NC Programmable, Green Terminal Interface |
|
Tracking Trigger Event
|
Zoom, Tracking, Recording, Preset, Snapshot, Alarm, etc. |
| Playback & Backup |
|
Playback
|
128 Mbps in Raid 5 Mode;
64 Mbps in single HDD Mode
|
|
Search Mode
|
Time/Date, Alarm, MD & Exact search (accurate to second) |
|
Playback Function
|
Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom |
|
Backup Mode
|
USB Device/Network/eSATA Device |
| Third-party Support |
|
Third-party Support
|
Snappy, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, and more |
|
|
