| System |
|
Main Processor
|
Intel Processors |
|
Operating System
|
LINUX |
| Video & Audio |
|
IP Camera Input
|
64 channel |
|
Two-way Talk
|
1channel Input, 1channel Output, RCA |
| Display |
|
Interface
|
2 HDMI (up to 3840x2160), 1 VGA |
|
Resolution
|
3840×2160, 1920×1080, 1280×1024, 1280×720, 1024×768 |
|
Multi-screen Display
|
The 1st screen: 1/4/8/9/16/25/36
The 2nd screen: 1/4/8/9/16 |
|
OSD
|
Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
| Recording |
|
Compression
|
H.264/MJPEG |
|
Resolution
|
12Mp, 8Mp, 6Mp, 5Mp, 3Mp, 1080P, 1.3Mp, 720P & etc. |
|
Record Rate
|
256Mbps |
|
Bit Rate
|
1~ 20Mbps |
|
Record Mode
|
Manual, Schedule(Regular(Continuous), MD(Video detection: Motion detection, Camera blank, Video loss), Alarm), Stop |
|
Record Interval
|
1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec |
| Video Detection & Alarm |
|
Trigger Events
|
Recording, PTZ, Tour, Alarm out, Video Push, Email, FTP, Snapshot, Buzzer & Screen tips |
|
Video Detection
|
Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank |
|
Alarm Input
|
16ch, low level effective, green terminal interface |
|
Relay Output
|
8ch, Relay contact(1A@24VDC), NO/NC programmable, green terminal interface |
| Playback & Backup |
|
Playback
|
128Mbps in Raid 5 mode
64Mbps in single HDD mode |
|
Search Mode
|
Time/Date, Alarm, MD & Exact search (accurate to second) |
|
Playback Function
|
Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom |
|
Backup Mode
|
USB Device/Network/Internal SATA burner/eSATA Device |
